FILM FORMAT | 35mm DIN 15
501 |
|
LENS MOUNT | 54mm
PL-mount adjustable for filming in Super 35 format |
|
FLANGE
FOCAL DISTANCE |
51.98 -
0.01 mm |
|
STANDARD MODEL | reflex mirror
shutter mechanically adjustable from 11.2° - 180° lockable in the following positions: 11.2°, 22.5°, 30°, 45°, 60°, 75°, 90°, 105°, 120°, 135°, 144°, 172.8° and 180° |
|
ES-MODEL | reflex
mirror shutter can be electronically adjusted continuously from 11.2° to 180° while the
camera is running or locked mechanically at fixed stops |
|
FRAME RATE | 1-150 fps,
forwards and reverse (quartz-accurate to 0.001 fps) standard speeds: 23.976 / 24 / 25 / 29.97 and 30 fps |
|
VIEWFINDER
INDICATOR |
asynchronous
film running, low battery voltage, film end |
|
CONTRAST FILTER | selectable,
ND 0.6 |
|
PHASE SHIFTER | integrated
into the camera, by pressing the PHASE key while camera is running |
|
SENSORS | shown on
the camera display are: film end, incorrect movement position. If the camera is not ready for operation, the control lamp illuminates red |
|
TEMPERATURE
RANGE |
-20°C /
+50°C (- 4° F / + 122° F) |
|
VIDEO ASSIST | C-mount for
1/2"-CCD camera or integrated Videoassist IVS |
|
BEAMSPLITTER | interchangeable
with ratios of 80/20% and 50/50% |
|
MAGAZINES | 400 ft /
1000 ft (120 m and 300 m) displacement magazines, backwards compatible with STEADICAM MAGAZINE 400 ft (120 m) ;35 III/2C magazines (no TC-recording with these older magazines) |
|
MOVEMENT SYSTEM | 5-link
movement with dual 3-pin pull-down claws and dual registration pins for 35mm negative film
DIN 15501 |
|
DRIVE SYSTEM | quartz-controlled
DC motors |
|
POWER SUPPLY | Up to 130
fps 24 V DC above 130 fps > 24 V DC |
|
BATTERY TYPE | NC 24/7R |
|
WEIGHT | 6.5 kg
(14.3 lbs) without magazine |
|
DIMENSIONS | with 400 ft
(120 m) magazine, without lens, length: 400 mm (15.75") width: 250 mm (9.84") height: 331 mm (13.03") |
|
TIME CODE | easily
mounted TC-recording module, format SMPTE RP 136, form C 80 bit. TC quartz accuracy 1 ppm (0-50°C). |
